Humidity Detector PCE-MA 202
Need Technical Support?
Our engineers are available to help you select the right module for your application.
Description
Description
Humidity DetectorPCE-MA 202
Oven-drying moisture analyzing balance for weighing and halogen-heating samples to determine moisture content
The humidity detector allows different materials to be weighed and their moisture contents determined. The heating chamber is heated by halogen lamps up to 199 °C. In this chamber, the humidity detector dries the material to be weighed, and then calculates the moisture content from the weight difference. The humidity detector can determine the smallest weight differences thanks to a readability of 0.01 g. The results are displayed on the large LCD display. Up to 15 different drying programs can be stored in the memory of the humidity detector. Accordingly, the humidity detector is suitable for quality control of wood products, granules, pellets, feed, food, pastes and more. With the included 100 g weight, the humidity detector can be calibrated at any time.
Highlights
- Readability: 10 mg / 0.01 g
- Heating chamber for moisture determination
- RS-232 interface
- Memory for up to 15 drying programs
- Adjustable drying temperature and time
- Ease of use
- Calibration function for readjustment
- 100 g calibration weight included
- Large LCD display with nine membrane keys
Specification
Technical specifications | |
| Weighing range | 200 g |
| Readability | 10 mg / 0.01 g |
| Heating element | halogen lamp |
| Temperature range | +40 ... +199 °C |
| Heating time | 1 ... 99 min. adjustable |
| Humidity measurement range | 0 ... 100 % |
| Readability | 0.1 % |
| Memory | 15 drying programs |
| Interface | RS-232 |
| Display | LCD, 9 membrane keys |
| Power supply | 220 V / 50 Hz or 110 v / 60 Hz |
| Dimensions | |
